| Product Model | TM-LF1330 |
| Laser Type | Fiber Laser |
| Maximum Cutting Thickness | 4.5MM(1000W)/7MM(1500W)/10MM（2000W) |
| Laser Source | FEIBO (Optional: IPG/Raycus) |
| Drive System | Gantry Dual Drive |
| Drive Mode | Precision double drive rack |
| Frame Structure | Industrial plate welding after high temperature annealing for stress relief |
| Maximum Acceleration | 0.8G |
| Maximum running speed | 80m/min |
| Processing area | 1300 X 3000 mm |
| Position accuracy | ±0.03mm |
| Power supply | 380V/50Hz |
| Control System | FSCUT1000 |
| Focusing method | Mmanual Focus |
| Cooling system | Industrial cycle water cooling |
| Net weight(kg) | 1500kg |
| Appearance Size | 4700X2400X2000mm |
